70 Options Guide RX200 S6
Further options
Ê Open the server as described in the chapter "Preparation" on page 25.
Figure 40: Installing the TPM module
Ê Insert the TPM spacer into the hole on the system board (1).
Ê Insert the TPM on the system board (2).
Ê Fasten the TPM with the special screw for the TPM (3).
Please use the TPM screwdriver insert bit to tighten the special screw.
I Do not fasten the screw too tightly (torque value of 0.6 Nm).
Ê Close the server, connect it to the power outlet, and switch it on as described
in the chapter "Completion" on page 73.
I You can find information on configuring the TPM in the "D3031 BIOS
Setup Utility for RX200 S6" manual.
1
2
3
1
2
3
