12 Appendix
12.1 Cabling
No. Part no. Description From To
1 A3C40102683 Front VGA cable Front panel board System board
2 A3C40102687 SATA ODD cable Optical Disk Drive
(ODD)
System board
(SATA ODD
connector),
HDD backplane
and ODD
3 A3C40102656 SAS HDD cable System board
(onboard SATA
connector) or RAID
controller in slot 3
HDD backplane
(CN1 or CN2)
4 A3C40102678 Front panel cable Front panel board System board
5 T26139-
Y3987-Vn
iBBU cable iBBU RAID controller
