3.3.2 Management Blade
Within the blade server management system there are two management blades. One of them is active as the
master of the server management system. The other one is in standby mode to ensure the availability of the
system.
A number of parameters relating to the management blades is displayed to the user, showing their current values
(see next figure):
Figure 5: Management Blade menu
The following parameters are displayed:
Parameter Description
Management Blade Run Mode Displays whether the management blade is run in master mode or slave
(standby) mode.
Management Blade Status Health status of the management blade. A message will be displayed if
this status is disturbed.
Management Blade Manufacture Name of the manufacturer of the management blade.
Management Blade Manufacture Date Date of manufacture for the management blade.
Management Blade Serial Number Serial number of the management blade.
Management Blade Product Name Product name of the management blade.
Management Blade Model Name Name of the management blade model.
Management Blade Hardware Version Hardware version of the management blade.
Management Blade Firmware Version Firmware version of the management blade.
Management LAN MAC Address Physical address (MAC address) of the management LAN interface of
the MMB.
Service LAN MAC Address Physical address (MAC address) of the service LAN interface of the
MMB.
Management Voltage Status Status of the voltage supply of the MMB.
Management Voltage Maximum Value Maximum voltage of the MMB.
Management Voltage Minimum Value Minimum voltage of the MMB.
Management Voltage Normal Value Standard voltage of the MMB.
Management Voltage Current Value Current voltage of the MMB.
