7.2 Replacing the Pad ASSY
ScanSnap S500 Operator's Guide 161
Replacing Consumables and Carrier Sheet
7
4. Attach the new Pad ASSY.
5. Close the ADF cover.
⇒ You should hear the ADF click when it returns to its original position.
Make sure that the Pad ASSY is completely attached. Otherwise, document
jams or other feeding errors may occur.
