3.3 Loading Documents
ScanSnap S500 Operator's Guide 43
Basic Scanner Operations
3
■ Loading Documents with the Carrier Sheet
The Carrier Sheet is a sheet for loading document specifically designed for ScanSnap S500/fi-
5110EOX2 Series. It allows you to scan documents that cannot be scanned as it is. A document
larger than A4 up to A3, B4 or 11 x 17 (single side) can be scanned by folding it in two, inserting it
into the Carrier Sheet and scanning in duplex mode.
You can scan documents that can be easily scratched such as photographs or irregular-shaped doc-
uments that are difficult to load on the scanner such as clippings of information (e.g. magazine and
newspaper).
The following explains how to insert documents into the Carrier Sheet.
There are two [Modes] which are tailored to the type of document to be scanned in the Carrier
Sheet settings.
Create facing pages in one image
(page 44)
Scan a document larger than A4 size such as A3/B4/
11" x 17" which is folded in two in duplex mode,
and then output an image arranged in two-page
spread and joined together.
Create front and back images
separately (page 49)
This mode is for scanning photographs which you do
not want to scratch, or documents of irregular size
such as clippings of information that are difficult to
load and scan directly on the scanner.
Output the scanned image in specified sizes.
ATTENTION
• When you use the Carrier Sheet, select [Automatic Detection] in the setting
of the [Paper size] tab in "ScanSnap Manager."
If scanning is done using "Create facing pages in one image", select "Duplex
Scan" in the setting of [Scanning] tab in "ScanSnap Manager." If you select
"Simplex Scan", it will produce the same result as using "Create front and
back images separately" to scan in simplex.
Refer to "3.6 Changing Carrier Sheet Settings" (page 86) for details on chang-
ing the "Carrier Sheet" Settings.
• If you are using the Carrier Sheet for scanning, it is not possible to scan multi-
ple sheets continuously. Load the sheets one by one and scan.

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
