2.2 Connecting ScanSnap to your PC
Follow the procedure below to connect ScanSnap to your personal computer.
1. Connect ScanSnap to a power outlet using the AC cable.
2. Connect ScanSnap to your personal computer using the USB cable.
The following describes each of the above two procedures.
■ Connecting the AC Adapter
Connect the power cable as shown below.
Operation
1. Connect the AC cable to the AC adapter.
2. Connect the AC adapter to the AC adapter connector on ScanSnap and to a power outlet.
ATTENTION
• Be sure to connect the AC cable first before connecting the USB cable.
• Be sure to install ScanSnap Manager to your personal computer before con-
necting ScanSnap to your personal computer. (For details about the installa-
tion, refer to "Installing the Supplied Programs for ScanSnap" (page 6)).
ATTENTION
Do not use cables other than the ones supplied with this product.
Use only specified AC cable and AC adapter.
AC cable
AC adapter
Outlet
Inlet

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
