Fujitsu ScanSnap S500 User Manual

2.1 Installing the Supplied Programs for ScanSnap
ScanSnap S500 Operator's Guide 11
Connecting ScanSnap
2
■ Installing ABBYY FineReader
Install ABBYY FineReader by using the following procedure from the "ABBYY FineReader CD"
supplied with the scanner.
Operation
Prepare the ABBYY FineReader CD.
1. Insert the ABBYY FineReader CD into the CD-ROM drive.
⇒ The "ABBYY FineReader for ScanSnap" screen appears.
ATTENTION
• If Windows Service Pack 2 is installed in your computer, you may see the fol-
lowing window when inserting the CD described above. Click the [Yes] button
to show the "ABBYY FineReader for ScanSnap" screen.
If the [In the future, do not show this message.] checkbox is marked, you will
not see this window when inserting a CD that attempts to connect to
Microsoft Internet Explorer in the future.
• You may see [Information Bar] instead of the one above. If so, first, click the
[OK] button and then the yellow part with a warning for options.
Next, select [Allow Blocked Content] from the menu.

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
