Fujitsu ScanSnap S500 User Manual

32
⇒ The lamp on the scanner lights blue during the scanning operation.
The following window appears to indicate the scanning status.
⇒ The supplied application (ScanSnap Organizer) is started up and the scanned image is
displayed.
For details about the settings for the scanning, file names and the destination folder to
save the data, refer to "3.4 Changing Scan Settings" (page 53).
About the scanning of Business cards, refer to "4.3 Scanning Business Cards" (page 122).
ATTENTION
• Do not connect or disconnect other USB devices during the scanning opera-
tion.
• Do not close the paper chute or press the [POWER] button on the scanner
during the scanning operation.
• Do not switch the user to log in during the scanning operation.
HINT
As the default setting, documents are scanned according with the following set-
ting: "Image quality: Normal" and "Color mode: Auto Color Detection."

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
