Fujitsu ScanSnap S510 User Manual

110
Length: 50.8 - 297 mm (2 - 11.69 in.)
•Type in a name you want to use for the custom size in the "Name"
field.
⇒The new name is added in the "Output image size" drop-down list.
3) When you finish, click the [OK] button.
⇒ A new custom size is added in the list.
4) Click the [Close] button to close the "Add or Remove custom sizes" dialog
box.
To delete custom sizes
1) In the "Add or Remove custom sizes" dialog box, select a custom size you
want to delete, and click the [Delete] button.
2) In the confirmation message window, click the [Yes] button.
3) In the "Add or Remove custom sizes" dialog box, verity that the custom size is
deleted, and then click the [Close] button.
To change settings
1) In the "Add or Remove custom sizes" dialog box, select a custom size you
want to change settings, and then click the [Change] button.
2) The "Additional custom sizes settings" dialog box appears. Make change to
meet your preferences.
3) When you finish, click the [OK] button.
⇒The "Add or Remove custom sizes" dialog box appears, and changes made
take effect.
4) Click the [Close] button to close the "Add or Remove custom sizes" dialog
box.

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
