Fujitsu ScanSnap S510 User Manual

5.4 Using the ScanSnap as a Copy Machine
ScanSnap S510 Operator's Guide 147
About Actions
5
Operation
3. Place the mouse cursor on [Scan2Print].
⇒ A description of the [Scan2Print] action is displayed.
4. When you want to change settings on the [Scan2Print] action, place the mouse
cursor on the ( ) mark, and then click the [Setting] button .
(If you want to use default settings, go to step 5.)
⇒ The following dialog box appears.
In this dialog box, you can change settings on the [Scan2Print] action as follows:
"Keep data used for printing as files" checkbox
Printed document images are saved in PDF format.
PDF files are saved in a folder specified in the "Image saving folder" drop-down
list on the [Save] tab of the "ScanSnap Manager - Scan and Save Settings" dialog
box (page 74).
(By default, this checkbox is not marked.)
"Show preview" checkbox
Before documents are printed, the print setup dialog box is displayed.
5. Click the [OK] button to close the "Scan2Print - Options" dialog box.

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
