158
To use this function, more than the recommended memory is required. If a
large number of pages are converted at one time, memory may become
insufficient during conversion.
In this case, change settings for virtual memory configuration, following the
procedure below.
Windows XP
1. Select [Start], right-click [My Computer], and then select [Properties] in
the pop-up menu.
2. In the "System Properties" dialog box,
select the [Advanced] tab, and then
click the [Settings] button under "Per-
formance."
3. In the "Performance Options" dialog
box, select the [Advanced] tab, and
then click the [Change] button under
"Virtual memory."
4. In the "Virthual Memory" dialog box,
select "Custom size, " and then type in
a rather large number
in the "Maxi-
mum size (MB)" field.
5. Click the [Set] button.
6. Click the [OK] button to close all dia-
log boxes.
Windows 2000
1. Right-click the [My Computer] icon on the Desktop, and then select
[Properties] in the pop-up menu.
2. In the "System Properties" dialog box,
select the [Advanced] tab, and then
click the [Performance Options] but-
ton under "Performance."
3. In the "Performance Options" dialog
box, click the [Change] button under
"Virtual memory."
4. In the "Virthual Memory" dialog box,
type in a rather large number
in the
"Maximum size (MB)" field under
"Paging file size for selected drive."
5. Click the [Set] button.
6. Click the [OK] button to close all dia-
log boxes.

Table of Contents

Other manuals for Fujitsu ScanSnap S510

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu ScanSnap S510 and is the answer not in the manual?

Fujitsu ScanSnap S510 Specifications

General IconGeneral
Film scanningNo
Color scanningYes
Input color depth- bit
Maximum scan size216 x 356 mm
Scanner typeSheet-fed scanner
Sensor typeCCD
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Auto document feeder (ADF) input capacity50 sheets
USB version2.0
Standard interfacesUSB 2.0
Minimum storage drive space512 MB
Minimum system requirementsWindows 2000/ XP/ Vista
Sustainability certificatesENERGY STAR
Power requirementsAC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
CertificationRoHS
Weight and Dimensions IconWeight and Dimensions
Weight2700 g
