Fujitsu ScanSnap S510 User Manual

18
7. Select "Typical," "Compact," or "Custom" from options and click the [Next] button.
Select [Typical] for ordinary use.
⇒ Clicking the [Next] button displays the "ScanSnap Manager Setting 1" dialog box.
8. In the "ScanSnap Manager Setting 1" dialog box, specify the method of loading the
document, and then click the [Next] button.
When you want to set the document upside down and face down on the ScanSnap, select the
left radio button.
When you want to set the document face up on the ScanSnap, check the right radio button.
HINT
Depending on the selected options, programs are installed as follows:
• Typical
ScanSnap Manager, ScanSnap Organizer, and CardMinder are installed
along with the manuals for these programs.
• Compact
ScanSnap Manager is installed along with its manual.
• Custom
Only the programs of your choice and the manuals of them are installed.

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
