Fujitsu ScanSnap S510 User Manual

36
4. Press the [SCAN] button on the ScanSnap.
⇒ The scanning is started.
⇒ The power indicator (lamp) on the ScanSnap blinks blue during the scanning operation.
The following window appears to indicate the scanning status.
⇒ When the scanning is complete, the ScanSnap Quick Menu appears.
HINT
• By default, documents are scanned in "Duplex" mode when you press the
[SCAN] button. In the "ScanSnap Manager - Scan and Save Settings" dialog
box, you can switch the scanning mode of the [SCAN] button to "Simplex"
mode.
• Scanning can also be started by using the ScanSnap Manager icon on
the task bar.
For details about this operation, refer to "4.1 About the ScanSnap Icon" (page
64).
ATTENTION
• Do not connect or disconnect other USB devices during the scanning
operation.
• Do not close the paper chute during the scanning operation.
• Do not switch the user to log in during the scanning operation. Otherwise, the
scanning is canceled.
S
S

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
