Fujitsu ScanSnap S510 User Manual

40
■ Scanning documents in Left-Click Menu Mode
Operation
1. Check for the ScanSnap Manager icon on the task bar as shown below.
2. Unmark
[Use ScanSnap Quick Menu] in the menu that pops up when the ScanSnap
Manager icon is right-clicked.
Operation
3. Load the document onto the ScanSnap.
Refer to "3.2 Paper Size of Documents to be Scanned" (page 46) and "3.3 Loading
Documents" (page 49) for more information.
HINT
If the ScanSnap Manager icon is not present on the task bar, from the [Start]
menu, select [All Programs]
 [ScanSnap Manager]  [ScanSnap Manager]
to start up ScanSnap Manager.
Generally, ScanSnap Manager is registered with "Startup," so that its icon
appears on the task bar when Windows starts up. If ScanSnap Manager is not
registered with "Startup," from the [Start] menu, select [All Programs]

[ScanSnap Manager]
 [Startup Register] to register it.
HINT
• When [Use ScanSnap Quick Menu] is marked, the document is scanned in
Quick Menu Mode. For details about the Quick Menu Mode, refer to "3.1 Flow
of Operations" (page 35).
S
S

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
