12
3. BASIC OPERATION
Status display mode Group control mode
All control mode
Any one of the setting button ALL / GROUP
After
1 minute
Operation display mode Control mode
Individual control mode
3. BASIC OPERATION
The following shows the two major screens of the display of the central remote controller.
• Operation display mode (monitor screen)
The operating condition of each remote control group that has been stored in the central remote
controller is displayed. When a central control number is selected with the button , the
current operating condition of the relevant indoor units is shown on the LCD.
If no action is taken, this mode will be shown.
• Control mode (Setting screen)
Control mode is used to set the items to be controlled to the remote control groups that has been
stored in the central remote controller. There are three control modes in the central remote con-
troller.
Individual control mode: Used for setting items to be controlled to a single remote control
group.
Group control mode: Used for setting items to be controlled to a grouped remote control
group.
All control mode: Used for setting items to be controlled to all of the remote control
group.
Individual control mode Group control mode All control mode
UTB-YCA.GCA_p12-18.p65 05.9.6, 2:35 PM12
