OUT LINE TESTER MODEL
■ OUT LINE TESTER MODEL
MODEL ＦＬ－ 2
① MODEL
Symbol Permissive Leak rangeApplication Application
8
±0.01～9.99 kPa
Middle Leak Detection
9
±1～999 Pa
Small Leak Detection
② CALIBRATOR (BUILT IN)
Symbol With/Without Calibrator Remarks
6 Without Calibrator
6A 1.0ml Calibrator
6B 0.1ml Calibrator
③ SET PRESSURE RANGE
Symbol
TEST PRESSURE RANGE SET PRESSURE RANGE DISPLAY PRESSURE RANGE
UL
-10.0～10.0kPa -10.0～10.0kPa -10.0～10.0kPa
L
-100～200kPa -100～200kPa -100～200kPa
H
-100～900kPa -100～900kPa -100～900kPa
④ POWER SUPPLY
Symbol POWER SUPPLY
0
AC100V ±10％ 50/60Hz
2
AC90～110V AC200～240V 50/60Hz
⑤ INTERNAL OPTIONS
Symbol OPTION REMARKS
R RS-232C Output
Select either RS-232C output (R) or printer
output (P).
P Printer Output
B1 Special Buzzer Sounding
Select either a “Beep” (B1) or a pulsed tone (B2)
for notification.
B2 Special Buzzer Sounding
E
Piping modification to correspond with
the external exhaust unit
Only for use with a vacuum
V
Manual valve position indication
switch
Only at work side
⑥ EXTERNAL OPTIONS see page 9.
① ② ③ － ④ ⑤ ⑥
