Fukuda FL-286 - Printer Connections; Specifications for Printer Output

65
PRINTER CONNENCTIONS
☆ This function is optional
● Print out evaluated data by connecting an external printer (e.g. FP-100) to the printer output port
located on the rear panel of the air leak tester.
● Following is the specifications for printer output.
・Text code ASCII
・Output Spec. Centronics Spec. Compliance
・Connector D Type Connector 36Pin
Number Signal Number Signal
1 STROBE 19 GND
2 DATA 0 20 GND
3
〃 1
21 GND
4
〃 2
22 GND
5
〃 3
23 GND
6
〃 4
24 GND
7
〃 5
25 GND
8
〃 6
26 GND
9
〃 7
27 GND
10 N/A 28 N/A
11
READY／BUSY
29 N/A
12
PAPER－END
30 FEED
13 N/A 31 N/A
14 +5V 32 +5V
15 GND 33 GND
16 GND 34 GND
17 N/A 35 N/A
18 N/A 36 N/A
＊When the printer’s BUSY signal is output at the beginning of the output timing, it will not start
printing.
