TESTER SPECIFICATIONS
■ PERFORMANCE SPECIFICATIONS
◆ Testing Method: Differential Pressure Comparison
◆ Leak Pressure Range・Measurement Accuracy
MODEL
Leak Pressure Measurement
Range
Measure
m
ent Sensor Accurac
y
(Including hysteresis)
FL-286
±0.01～9.99kPa ±5％F.S.（10.00kPa）
FL-296
±1～999Pa ±5％F.S.（1000Pa）
Direct Pressure Sensor Accuracy
MODEL Pressure Measurement Range
Measurement Sensor Accurac
y
(Including hysteresis)
UL
-10.0～10.0kPa ±5％F.S.（-10.0kPa、10.0kPa）
L
-100～200kPa ±5％F.S.（-100kPa、200kPa）
H
-100～900kPa ±5％F.S.（-100kPa、900kPa）
■ FUNCTION SPECIFICATIONS
Timer Setting Range
DLY
CHG
BAL
DET
EXH
（Delay）
（Charge）
（Balance）
(Detection)
(Exhaust)
0.0 ～ 999.9sec
0.1 ～ 999.9sec
0.1 ～ 999.9sec
0.1 ～ 999.9sec
0.2 ～ 999.9sec
Group Setting Function
4ch(DLY time, CHG time, BAL time, DET time, EXH time, -NG set,
+NG set, -NG set(leak amount), +NG set(leak amout), P.NG value,
Volume value, -NG unit (leak amount), +NG unit(leak amount),
Volume unit, Leak amout indication unit)
Supplemental Functions
BUBL（Bubble）,CAL（Calibration）, Cylinder Control
Test circuit internal volume
8 ml（when rear panel stop valve is closed）
Displa
y
Digital indication in four digi
t
External Input/Output
1. Contact input/output for control 38
P
2. Option input/output
・Output for printer（Centronics-compliant output system）
・RS-232C input/output with PC
■GENERAL SPECIFICATIONS
Operation Temperature Range
0～40℃
Operation Humidity Range
35～85％RH（without condensation）
Power Source
A
C100V±10％ 50/60Hz
AC90～110V AC200～240V 50/60Hz
Power Consumption 150VA
Voltage enduranc
e
A
C1000V 1 minut
e
Insulating Resistanc
e
More than 50MΩ at DC500V
Leak Curren
t
Less than 1mA at AC100V
Pressure enduranc
e
UL Range：-50～+50kPa、L Range：-100～+600kPa、H Range：-0.1～+1.5MPa
Dimensions Function
W172.9 mm×H272.8 mm×D386 mm（Without external option）
Weight
Power Sourc
e
100V:
A
bout 9.5 kg
Power Source 200V:About 10.5 kg
Air Specifications
Please supply clean , stable , and dry air
Recommended Condition: Based on JISB8392-1:2000
Compressed Air Quality Class1,3,1
Class
A
rticle Referenc
e
1 Maximum Particle Diameter
0.1μm
3
Minimum Pressure De
w
-poin
t
-20℃
1 Maximum Oil Conten
t
0.01mg/
m
3
