Fukuda FL-286 - Test Data Communication Sample

Test Data Communication Sample
COMMAND
GROUP TEST NUMBER JUDGMENT RESULT MEASURED VALUE TEST PRESSURE END
BYTE
1 2 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2
OK WORK TEST
（DIFF. PRESSURE JUDGE）
0 4
0 1 O K 0 1 0 0 CR
LF
OK WORK TEST
（LEAK AMOUNT JUDGE）
0 4
0 2 O K 0 . 0 4 1 0 1 CR
LF
LARGE LEAK WORK TEST
（WORK SIDE）
0 4
0 3 B
+ N G 5 1 . 2 3 1 0 2 CR LF
LARGE LEAK WORK TEST
（MASTER SIDE）
0 4
0 4 B
- N G - 6 2 . 3 4 1 0 1 CR LF
SMALL LEAK WORK TEST
（WORK SIDE）
0 4
0 5 D
+ N G 1 . 1 2 1 0 1 CR LF
SMALL LEAK WORK TEST
(MASTER SIDE）
0 4
0 6 D
- N G - 2 . 3 4 1 0 2 CR LF
UNMEASURABLE
（WORK SIDE、OCCUR DURING ＢＡＬ ）
0 4
1 1 1 B
+ N G 1 0 0 CR LF
UNMEASURABLE
（MASTER SIDE, OCCUR DURING BAL）
0 4
1 1 2 B
- N G 1 0 0 CR LF
UNMEASURABLE
（WORK SIDE, OCCUR DURING DET）
0 4
2 1 1 1 B
+ N G 1 0 0 CR LF
UNMEASURABLE
（MASTER SIDE, OCCUR DURING DET）
0 4
2 1 1 2 B
- N G 1 0 0 CR LF
CHARGE SHORTAGE
（LOWER THAN ＰＮＧ SET VALUE）
0 4
3 1 2 3 4 P
. N G - 1 0 CR LF
CHARGE SHORTAGE
(BY PRESSURE SW）
0 4
3 1 2 3 5 P
. N G CR LF
・ All communication data are ASCII strings.
・ Space (20hex) is put in the blank.
・ Measured value and test pressure are signed. The space (20hex) is put in case of ＋, and － sign is put in the 3
rd
byte.
・ CR of the END is ０Ｄhｅｘ, and LF is ０Ａhｅｘ.
・ The test number is counted in each group. If exceeding 9999, it returns to 1, and also returns to 1 by power OFF.
63
RS-232C
CONNECTION
