INSTALLATION - 2
2.3 MAJOR COMPONENTS
Boiler/Pressure vessel. Mounted inside the cabinet in the lower half.
Feedwater and condensate return tank. Mounted inside the cabinet in the upper half.
Operator control panel. Mounted inside the cabinet behind the front access panel and
accessible with the access panel attached..
Electrical control panel. Mounted inside the cabinet in the upper half behind the front access
panel. Panel must be removed for access.
Operating pressure controls
Boiler feedwater pump (Grundfos). 1 x Grundfos feedwater pump is provided for the boiler
feedwater mounted to the base of the cabinet.
For more information on the feedwater pump, please refer to the Grundfos OEM literature.
Steam pressure gauge. Fitted to the cabinet frame and visible from the front with the access
panel attached.
Steam outlet valve.Steamoutletstopvalvettedcentrallytotherearofthecabinet.
Safety valve. Fitted to the rear of the cabinet.
Main boiler blowdown valve. Fitted centrally to the rear of the cabinet at the bottom.
Water level gauge set (sight glasses) (optional). Fitted to the side of the cabinet.
2.3.1 STEAM SAFETY VALVES
Safetyvalvesarefactoryttedandpre-set,theyMUSTNOTbeadjusted.Thedischargeoutlet
should be piped to a safe discharge point and the piping so arranged that any condensate
trapped in the pipework will drain away from the valve.
Note: It is recommended that the safety valve discharge pipework is installed to the requirements of BS806
clause 4.9.7. / BSEN 134801-1:2002
a) The lift pressure is indicated on the safety valve (donotadjust).
b) Thesafetyvalvettedtotheboilerisdesignedtopreventtheboilerexceedingitsdesign
pressure.
c) Any system connected to the boiler not capable of accepting boiler pressure must be protected
by a separate safety valve set to the required pressure.
WARNING
Factoryttedsafetyvalvesarepre-settoprotecttheboileronlyandmustnotbeusedtoprotectany
other items not capable of accepting boiler pressure.
!
