FULTON Electropack Series - Page 15

EP18-72-IOMM-2015-7
Fulton Ltd
Page 9
INSTALLATION - 2
Supply cable access hole
(twithaglandnutsuitablefor
the electrical supply cable used)
Door electrical isolator
(supply cable connection point)
Figure. 4 - Electrical Supply Cable Location
Fuse holders / MCB’s
Electrical supply
access hole
Element contactors
Door electrical
isolator switch
Circuit breakers
LC relays
Miniature relays
Pump overload
Cooling fan
Transformer
Pump contactor
N.B. Control Panel frame is
unbolted on right hand side to
allow complete access to the
main electrical panel
Figure. 5 - Electrical Connections
