User Manual
Warranty
5.2 Technical Data
PRODUCT DESCRIPTION: IEEE 802.11g WLAN access point
ANTENNA: Detachable 5dBi RSMA antenna
OUTPUT POWER: 14 dBm + 5 dBm antenna gain
SENSITIVITY: 11g @ PER 10% 54 Mbps <= -65 dBm;
11b @ PER 8% 11 Mbps <= -80 dBm
MODULATION: 11g (OFDM) 64QAM, 16QAM, QPSK, BPSK;
11b (DSSS) CCK, DQPSK, DBPSK
RANGE: 11g: 54 Mbps up to 60 meters, 11 Mbps
up to 120 meters; 11b: 11 Mbps up to 80
meters, 1 Mbps up to 200 meters
FREQUENCY BAND: Europe (ETSI) 13 channels: 2.412 GHz –
2.472 GHz
INTERFACE
A 10/100 Base-T Ethernet interface with
Auto MDI(X) support
OPERATION MODES: access point, repeater, bridge and wireless
client
SECURITY: WPA/WPA2, 802.1x, WEP 64/128/154-bit
DIMENSIONS: 110mm x 125mm x 30mm (LxWxH)
WEIGHT: approx. 200g
TEMPERATURE RANGE:
Operation 0 to 50°C, storage -10 to 65°C
AIR HUMIDITY: 90% (not condensing)
WARRANTY: 24 months
