3 Physical Structure
Figure 3-1 5288 V5 physical structure
1
I/O module 1
2
I/O module 2
3
Rear drive
4
Rear-drive backplane
5
I/O module 3
6
Chassis
7
Power supply unit (PSU)
8
(Optional) built-in drive
module
a
9
(Optional) air duct
a
10
Supercapacitor
