FusionServer 5288 V5 Server
Technical White Paper
5 Hardware Description
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
57
Figure 5-39 Fan module positions
5.10 Boards
5.10.1 Mainboard
⚫
BOM code for mainboards of enhanced management chip (VB): 0302021706, 0302Y076.
⚫
BOM code for mainboards of normal management chip: 03024AFQ, 03026NEA, 06410432,
03024CXS, 03029JRP, 06410436, 06410592.
