Fusion FusionServer 5288 V5 - Memory Compatibility

FusionServer 5288 V5 Server
Technical White Paper
5 Hardware Description
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
21
CPU
Memory Channel
Memory Slot
D
DIMM131(J)
E (primary)
DIMM140(E)
E
DIMM141(K)
F (primary)
DIMM150(F)
F
DIMM151(L)
5.4.1.3 Memory Compatibility
Observe the following rules when configuring DDR4 DIMMs:
⚫
A server must use the same model of DDR4 DIMMs, and all the DIMMs operate at
the same speed, which is the smallest value of:
⚫
Memory speed supported by a processor
⚫
Maximum operating speed of a DIMM
⚫
The DDR4 DIMMs of different types (RDIMM and LRDIMM) and specifications
(capacity, bit width, rank, and height) cannot be used together.
⚫
Contact your local sales representative or use the Compatibility Checker to
determine the components to be used.
⚫
The memory can be used with Intel
®
Xeon
®
Scalable Skylake and Cascade Lake
processors. The maximum memory capacity supported varies depending on the
processor model.
− Skylake processors
◼ M processors: 1.5 TB/socket
◼ Other processors: 768 GB/socket
− Cascade Lake processors
◼ L processors: 4.5 TB/socket
◼ M processors: 2 TB/socket
◼ Other processors: 1 TB/socket
⚫
The total memory capacity is the sum of the capacity of all DDR4 DIMMs.
