FusionServer 5288 V5 Server
Technical White Paper
5 Hardware Description
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
43
Indicator
Description
Data transmission rate
indicator for a 10GE
electrical port
⚫
Off: The network port is not connected.
⚫
Steady green: The data transmission rate of the link is
10 Gbit/s.
⚫
Steady yellow: The data transmission rate of the link is
1 Gbit/s.
Connection status
indicator of a GE
electrical port
⚫
Off: The network port is not connected.
⚫
Steady green: The network port is properly connected.
Data transmission
status indicator of a GE
electrical port
⚫
Off: Inactive.
⚫
Steady yellow: Active, but no data is being transmitted.
⚫
Blinking yellow: Data is being transmitted.
5.6.2 FlexIO Cards
FlexIO cards provide network expansion capabilities.
⚫
The FlexIO card (with electrical ports) cannot be connected to power over
Ethernet (PoE) devices (such as a switch with PoE enabled). Otherwise, link
communication failure or even damage to the FlexIO card may be caused.
⚫
Contact your local sales representative or use the Compatibility Checker to
determine the components to be used.
⚫
When IB cards are used to build an IB network, ensure that the IPoIB modes of
the IB cards at both ends of the network are the same. For details, contact
technical support.
Table 5-17 FlexIO cards supported by the 5288 V5 (example)
NIC Model
Chip Model
Port Type
Number of
Ports
Support
NC-SI/WOL/P
XE
SM210
5719
GE electrical
port
4
√
SM211
i350
GE electrical
port
2
√
SM212
i350
GE electrical
port
4
√
SM233
X540
10GE
electrical port
2
√
SM251
CX3
56G IB optical
port
2
×
SM252
CX3
56G IB optical
port
1
×
