FusionServer 5288 V5 Server
Technical White Paper
5 Hardware Description
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
17
Port Description
Table 5-4 Description of ports on the rear panel
Tool
Type
Quantity
Description
LOM port 1
10GE SFP+ or
10GE BASE-T
4
10GE LOM service ports
(optical/electrical). Use the
optical or electrical ports based
on service requirements.
For details, see 5.6.1 LOMs .
LOM port 2
1000BASE-T
2
GE LOM service ports
(electrical).
For details, see 5.6.1 LOMs .
VGA port
DB15
1
Used to connect a display
terminal, such as a monitor or
KVM.
Serial port
RJ45
1
Default operating system serial
port used for debugging. You
can also set it as the iBMC
serial port by using the iBMC
command.
NOTE
The port uses 3-wire serial
communication interface, and the
default baud rate is 115,200 bit/s.
Management
network port
1000BASE-T
1
Used for server management.
NOTE
The management network port is a
GE port that supports 100 Mbit/s
and 1000 Mbit/s auto-negotiation.
USB port
USB 3.0
2
Used to connect to a USB
device.
NOTICE
Before connecting an external
USB device, check that the USB
device functions properly. The
server may operate abnormally if
an abnormal USB device is
connected.
PSU socket
-
2
Used to connect to the power
distribution unit (PDU) in the
cabinet. You can select the
number of power supply units
(PSUs) as required.
NOTE
⚫
When determining the quantity
of PSUs, ensure that the rated
