FusionServer 5288 V5 Server
Technical White Paper
Copyright © xFusion Digital Technologies Co., Ltd.
disconnection and disable the WOL function of the LOM
ports. To restore the NC-SI connection, refresh the iBMC
WebUI.
10 PCIe 3.0 slots:
⚫
One slot dedicated for a screw-in RAID controller card,
one dedicated for a FlexIO card, and eight for standard
PCIe cards.
For details, see 5.7.2 PCIe Slots and 5.7.3 PCIe Slot
Description.
⚫
Support PCIe SSD cards to bolster I/O performance
for applications such as searching, caching, and
download services.
⚫
When IB cards are used to build an IB network, ensure
that the IPoIB modes of the IB cards at both ends of
the network are the same. For details, contact
technical support.
NOTE
The preceding information is for reference only. Use the
Compatibility Checker to obtain specific information.
Supports a variety of ports.
⚫
Ports on the front panel:
− Two USB 2.0 ports
⚫
Ports on the rear panel:
− Two USB 3.0 ports
− One DB15 VGA port
− One RJ45 serial port
− One RJ45 system management port
− Two GE electrical ports
− Two 10GE electrical ports or 10GE optical ports
⚫
Built-in ports:
− One USB 3.0 port
− Two SATA ports
NOTE
You are not advised to install the operating system on the USB
storage media.
An SM750 video chip with 32 MB display memory is
integrated on the mainboard. The maximum display
resolution is 1920 x 1200 at 60 Hz with 16 M colors.
NOTE
⚫
SM750 is not supported by servers running the Windows
Server 2019 or Windows Server 2019 Hyper-V operating
systems that are in secure boot mode.
⚫
The integrated video card can provide the maximum display
resolution (1920 x 1200) only after the video card driver
matching the operating system version is installed.
Otherwise, only the default resolution supported by the
