FusionServer 5288 V5 Server
Technical White Paper
A Appendix
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
86
Figure A-8 Example SN
Table A-5 SN description
No.
Description
1
ESN ID (two characters), which can only be 21.
2
Material ID (eight characters), that is, the processing code.
3
Vendor code (two characters), that is, the code of the processing
place.
4
Year and month (two characters).
The first character indicates the year.
Digits 1 to 9 indicate years 2001 to 2009, respectively.
Letters A to H indicate years 2010 to 2017, respectively.
Letters J to N indicate years 2018 to 2022, respectively.
Letters P to Y indicate years 2023 to 2032, respectively.
NOTE
The years from 2010 are represented by upper-case letters excluding I, O,
and Z because the three letters are similar to the digits 1, 0, and 2.
The second character indicates the month.
Digits 1 to 9 indicate January to September, respectively.
Letters A to C indicate October to December, respectively.
5
Serial number (six digits).
6
RoHS compliance (one character). Y indicates RoHS compliant.
7
Internal model (product name) of the board.
A.3 Operating Temperature Limitations
Table A-6 Operating temperature limitations
Configuratio
n
Max. 30°C (86°F)
Max. 35°C (95°F)
Max. 40°C (104°F)
Single RAID
configuration
(with built-in
drives)
Platinum
8180/8168/8280/
8270/8268 and
Gold
Options not
supported:
Platinum
8180/8168/8280/
Options supported:
Platinum
8153/8253, Gold
6152/6140/6126/
