FusionServer 5288 V5 Server
Technical White Paper
A Appendix
Issue 07 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
88
Configuratio
n
Max. 30°C (86°F)
Max. 35°C (95°F)
Max. 40°C (104°F)
⚫
Built-in drives
⚫
NVMe drives in
slots 32 to 35
⚫
PCIe SSD cards
⚫
When a single fan is faulty:
⚫
The maximum operating temperature is 5°C (9°F) lower than the rated value.
⚫
Drive performance will be affected if rear NVMe drives are configured.
⚫
If P4 GPU cards are configured:
⚫
The processor power consumption must be lower than 130 W if the server is configured with
six P4 GPU cards.
⚫
The processor power consumption of the processor must be lower than 205 W if the server
is configured with four P4 GPU cards. In addition, the P4 GPU cards must be installed in
slots: Slot 1, 2, 4, and 5.
⚫
The server supports the maximum operating temperature of 30°C (86°F) if the P4 GPU
cards are stacked and supports 35°C (95°F) if the P4 GPU cards are not stacked.
A.4 Nameplate
Certified Model
Usage Restrictions
H52H-05
Global
A.5 RAS Features
The server supports a variety of Reliability, Availability, and Serviceability (RAS)
features. You can configure these features for better performance.
For details about how to configure these features, see the Server Purley Platform
BIOS Parameter Reference.
Table A-7 Supported RAS features
Module
Feature
Description
CPU
Corrected Machine Check
Interrupt (CMCI)
Corrects error-triggered interrupts.
Memory
Failed DIMM Isolation
Identifies faulty DIMMs to facilitate
isolation and replacement of the faulty
DIMMs.
Memory Thermal Throttling
Automatically adjusts the memory
temperature to prevent the memory from
being damaged due to overheat.
