18
Digital Trims T1-T4
Digital trim operational example
T1T4
T3 T2
Elevator Neutral
Elevator Down
◆When the airplane goes up while the
elevator stick is neutral.
◆When the airplane dives while the
elevator stick is neutral.
◆Adjust so that the airplane flies level.
Elevator Neutral
Elevator Up
◆Elevator trim to down
◆Elevator trim to up
This transmitter is equipped with 4 digital trims.
Each time you press a trim button, the trim position
moves one step. If you continue pressing it, the trim
position starts to move faster. In addition, when
the trim position returns to the center, the tone will
change. You can always monitor trim positions by
referencing the LCD screen.
*You can select the trim step amount and the display unit
on the home screen on the T1-T4 setting screen within the
linkage menu.
Note: The trim positions you have set will be stored in the
non-volatile memory and will remain there.
*Example Stick Mode2
Long push the trim as it
is to reset it to neutral.
