FUTABA T16IZ - System Menu; Linkage Menu

36
The System menu sets up functions of the
transmitter. This does not set up any model data.
● When the System menu button is tapped,
the menu shown below is called up. Tap the
function button that you want to enter.
SYSTEM MENU
LINKAGE MENU
The Linkage menu is made up of functions which
perform model addition, model type selection, end
point setting, and other model basic settings.
System menu functions table
Display
Display adjustment.
Sound volume
Adjust the volume of: Other sound, Warning, Voice
System timer
Resets the system timer.
H/W setting
Stick mode selection (Mode 1 - Mode 4 ). J1-J4 sticks correction can be performed.
Battery
Battery alarm voltage setting. Auto power o󱐯 time setting.
Range check
The output of the transmitter is lowered, for Range checking.
S.Bus servo
S.Bus servo setting.
Information
Sets the User name, Language, and Unit system. Displays the program version, and micro SD card information.
Linkage menu functions table
Servo monitor
Displays the servo test and operation position
Model select
Model addition, call, deletion, copy, model name setting
Model type
Model type, wing type, tail type, swash type, selection
Servo reverse
Servo direction reversal
End point
Servo basic rate adjustment and limit setting
Servo speed
Servo speed setting
Sub-trim
Adjusts the neutral position of each servo
Function
Channel assignment of each function can be changed
Fail safe
Fail safe function and battery fail safe function setting
System type
System mode selection, link of a transmitter and receiver, telemetry mode selection
Trim setting
Control step amount and mode selection of the digital trim
Throttle cut
Stops the engine safely and easily
Idle down
Lowers the idle speed of the engine
Swash ring
Limits the swash plate travel to within a xed range. (helicopter only)
Swash
Swash AFR and linkage correction function (helicopter only except swash type H-1)
Stick alarm
Can be set so that an audible alarm sounds when the throttle stick reaches the set position.
Timer
Timer setting
Function name
Function name can be changed
Sensor
Various telemetry sensors setting
Telemetry
Displays various data sent from the receiver
Tele.setting
Telemetry data log
Trainer
Starts and sets the trainer system.
Warning setting
Mixing, throttle position warning reset
User menu setting
Original menu making
Date reset
Model memory set data reset (by item)
