FUTABA T16IZ Short Manual

22
Open the rubber cover
CAUTION
Be sure to turn off the power to
the transmitter before inserting or
removing the micro SD card.
As the micro SD card is a precision
device, do not use excessive force when
inserting.
-When an micro SD card is installed in
the T16IZ transmitter, a folder called "Fu
-
taba" is created. Folders called "LOG" and
"MODEL" are created in this folder. The
"MODEL" folder stores the model data and
the "LOG" folder stores the telemetry log
data.
-The telemetry log data recorded on the
micro SD card can be converted to CSV
format by the telemeter log converter re
-
leased on our home page. When copying or
moving a log le, always select both .FLI
and .FLD le.
Connector for trainer function
When you use the trainer function, connect the
optional trainer cable between the transmitters for
teacher and student.
*You can set the trainer function on the Trainer Function
screen in the System menu.
Connector/Plug
Trainer
Connector
S.BUS (S.I/F)
Connector
Earphone
Plug
S.BUS connector (S.I/F)
When using an S.BUS servo and telemetry sensor,
connect them both here.
Earphone plug
Connecting a stereo headphone to this plug, the
speech information of telemetry can be heard.

FUTABA T16IZ Specifications

General

Channels	16
Frequency	2.4GHz
Telemetry	Yes
Voice Alerts	Yes
SD Card Slot	Yes
USB Port	Yes
Trainer Port	Yes
Modulation	T-FHSS, S-FHSS
Display	4.3-inch color touchscreen
Battery	7.4V 2000mAh
Model Memory	30 models
