9
Features
FASSTest system
The T16IZ transmitter has adopted the bidirectional communication system "FASSTest". Data from the receiver can be checked in
your transmitter. FASSTest is a maximum 18 channels 2.4 GHz dedicated system.
Color touch screen LCD
T16IZ has an HVGA 4.3 inch, full-color, backlit LCD touch screen. The screen is transflective which enables both indoor and
outdoor visibility.
S.BUS2 system
By using the S.BUS2 system multiple servos, gyros and telemetry sensors are easily installed with a minimum amount of cables.
Model types
Multicopter. 8 swash types are available for helicopters. 7 wing types and 3 tail types are available for airplanes and gliders.
Functions and mixing functions necessary for each model type are set in advance at the factory.
Lithium-ion polymer battery
T16IZ is operated by a 7.4 V/2,000 mAh Lithium-ion polymer battery.
micro SD card (Secure Digital memory card) (Not included)
Model data can be saved to an micro SD card (SD:32MB-2GB SDHC:4GB-32GB). When T16IZ transmitter software files are
released, the software can be updated by using an micro SD card update.
Edit button
Two edit buttons are provided, and the operating screen can be immediately “Returned” to the HOME screen during operation.
Setting operation can be performed easily by combining this button with a touch sensor.
Vibration function
Selects a function that alerts the operator to various alarms by vibrating the transmitter in addition to sounding a buzzer.
Speech function
A function is equipped which allows the system to provide telemetry data audibly. This function can also be utilized with
commercially available earphones.
Contents and Technical Specications
(Specications and ratings are subject to change without notice.)
• T16IZ Transmitter
• R7108SB Receiver
• LT2F2000B LiPo Battery
Transmitter T16IZ
(2-stick, 18-channel, FASSTest-2.4 GHz system)
Transmitting frequency: 2.4 GHz band
System: FASSTest 18CH/FASSTest 12CH/S-FHSS/T-FHSS/
FASST MULT(Europe is not supported)/FASST 7CH(Europe is not supported) switchable
Power supply: 7.4
V LT2F2000B LiPo battery
Frequency band: 2.4 GHz
RF power output : 2
8 mW
Receiver R7108SB
(FASSTest-2.4 GHz system, Dual Antenna Diversity, S.BUS/S.BUS2 system)
Power requirement: 3.7 V-7.4 V battery or regulated output from ESC, etc. (*1)
Size: 0.98 x 1.86 x 0.56 in. (24.9 x 47.3 x 14.3 mm)
Weight: 0.42 oz. (12.0 g)
Frequency band: 2.4 GHz
RF power output: 25 mW EIRP
(*1) When using ESCs make sure that the regulated output capacity meets your usage application.
Note: This set does not include a charger. Use a commercially available USB charger AC
adapter (USB-A type 5 V-2 A) or the Futaba optional USB AC adapter.
Note: The battery in the T16IZ transmitter does not arrive already attached to the battery
connector. Please connect the battery connector before use.
• USB Cable
• Hex Key
• Tx Strap
• Short Manual
*The contents may vary on the type of set.
