170
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
This section contains information on the commands
that apply to helicopters only. For instructions
on airplane, glider and multicopter, refer to the
sections pertaining to those aircraft.
Use the Model type function in the Linkage menu
to select the swash type matched to the fuselage
beforehand.
$OVRDGGÀLJKWFRQGLWLRQVDWWKH&RQGLWLRQ6HOHFW
screen if necessary before setting the model data at
each function. (Up to 8 conditions can be used)
The AFR function, dual rate function and other
functions common to all model types, are described
in a separate section.
◆ Conditionhold
When performing adjustments, such as idling up, when the engine is
engaged, keep the throttle stable so as to prevent the engine from revving
too high. Once your adjustments are complete, always make sure to set
the function to [OFF].
*Condition hold ON/OFF operation is possible under normal condi
tions
and
the throttle stick is more than 1/3rd into the slow throttle range.
Throttle servos will remain at the throttle stick position during ON
operation.
● ON/OFFoperationontheHomescreen
Under the conditions described above, tap the Condition hold [OFF]
displayed on the screen.
During function operation, Condition hold will display [ON] and an
alarm will sound.
WARNING
Forsafetyreasons,whenperformingindividual
adjustmentsitisrecommendedthatyoushutoff
theengineanddisconnectthemotortoprevent
rotation.
*Sudden,abruptrotationcanresultindeathorseriousinjury.
ŰŲŧŨůŃŰŨűŸ
Ńŋ ūƈƏƌƆƒƓƗƈƕ ŃƉƘƑƆƗƌƒƑƖŌ
ŰƒƇƈƏŃƐƈƑƘŃŋūƈƏƌƆƒƓƗƈƕŌŃƉƘƑƆƗƌƒƑƖŃƗƄƅƏƈ
Servomonitor
Displaystheservotestandoperationposition
Conditionselect
Flightconditionsaddition,deletion,copy,conditionrenaming,andconditiondelaycanbeset.
AFR
Setstheangleandcurveofalltheoperationfunctions.
Dualrate
D/Rcurvewhichcanbeswitchedwithaswitch,etc.canalsobeadded.
Program.mixes
Programmixingwhichcanbefreelycustomized.Upto10mixescanbeusedforeachcondition.
Sequencer
Settingtheoperatingtimingofthelandinggearandgearcover.→P.131
Pitchcurve
Pitchcurveandhoveringtrimadjustment
Throttlecurve
Throttlecurveandhoveringtrimadjustment
Acceleration
Allowsabrief"overload"inresponsetosuddenthrottleandpitchcommands
Throttlehold
Movesthethrottletoidleduringautorotation
Swashmixing
Compensatesforeachcontrolresponse
Throttlemixing
Compensatesforpowerlosswhencyclicapplied
Pitch → Needle
Adjustsresponsecurveindifferentflightconditions
Pitch → Rudder
Handlestorquechangesfrompitchangleinputs
Gyro
Usedtoswitchgyrosensitivity
Governor
UsedtoswitchRPMofthehelicopterʼshead
Gyrosetting
DetailedsettingofCGY770R
