Operators and Technicians Manual
© 2002 – 2007 FutureLogic, Incorporated. All Rights Reserved. MNL Page 24 of 52 12/07/2007
MNL-000003 REV.N
Appendix A Technical Specifications
This appendix identifies the general specifications of the GEN2 printer.
General
Dimensions (WxDxH) 110mm x 304.8mm x 64.3mm
Weight 2.7 lbs.
Power Requirements 24VDC @ 2.7A avg.
Sensors Paper Low, Paper Out, Printer Drawer Open, Ticket Taken, Ticket Jam, Ticket
in Chute, Black Mark
(Includes a Host Controllable Buzzer)
Printing Speed 90mm/Second (3.5”/Second)
Print and Present 2.2 Seconds
Printing Width 62mm (true near-edge printing)
Storage 300 Tickets
Ticket Tray Extenders Interchangeable, 600, 900 Ticket Tray
Resolution 8 dots/mm (203 dpi)
Firmware Application in Memory is Reprogrammable (via Flash BIOS)
Self Test Yes
Page Mode Full Page Mode Printing (Simultaneous 4 Orientation Printing:
0°, 90°, 180°, 270°)
Line and Box Draw Printer Resident
Bitmap Graphics
Printer Resident (Stored in Flash) Graphics
Paper Loading Automatic Hands Free
Paper Feed Manual
Method Direct Thermal, Top Coated, Fanfolded and Perforated
Width 66mm
Length 156mm
Thickness 4.5 mil, 1 Color/2 Colors
Bezel Control Two High Current Ticket Printing Bezel Control Ports
User Interface 4 LED Indicators, Paper Advance Button
Update Port Allows for Printer Upgrades via Handheld Download Tool
Hot Swappable 100%
Printing Resources
Template Capacity 8MB; Stores hundreds of clip art objects & thousands of graphic templates
Graphic Storage 6MB
Color Printing Red on Black and Blue on Black are available. Other colors can be supported
as the print media becomes available. Color selection is controlled through
the TCL language.
