Operators and Technicians Manual
© 2002 – 2007 FutureLogic, Incorporated. All Rights Reserved. MNL Page 32 of 52 12/07/2007
MNL-000003 REV.N
Appendix D Part Numbers – Bezels
The following bezel systems are designed to bolt to the four M3 holes on the front chassis
plate of the GEN2 printer.
P/N Description
130-00024-100 Bezel RoHS
130-00007
Bezel Assembly, Ticket Out, EZ Pay
130-00008
Bezel Assembly, Ticket Out, LXS, S/T, EZ Pay
130-00017-100
Bezel Assembly, Top Box, EZ Pay RoHS
130-00009-100 Bezel, BZL,SHORT,ANGLED_FLG,ROHS,YEL
130-00021-100 Bezel, BZL,LONG,ANGLED_FLG,ROHS,YEL
310-00239
Bracket, Bezel, 19” Upright, GK+SST
310-00240
Bracket, Bezel, 19” Upright, GKTIGOLD
