Appendix B Paper Specifications
This appendix provides information on the paper used in the GEN2 printer. Please contact
FutureLogic, Inc. or your sales representative for more information on approved papers and
complete paper specifications.
For authorized ticket converters, visit our Web site:
www.futurelogic-inc.com.
Note: Use only approved paper in the printer. Use of improper paper may cause
damage to the device and will void the printer’s warranty.
Nominal paper thickness: 4.5mil
Paper dimensions: 65mm x 156mm (width dimension +
1mm
Ticket Stack
Ticket, 300STK, 65X156, 5M, Fanfold
Ticket, 600STK, 65X156, 5M, Fanfold
Ticket, 900STK, 65X156, 5M, Fanfold
Note: Paper width is +0mm, –1mm.
Figure B-1 Ticket Dimensional Specification
