Section 50 00-02-1032
2020-12-08 - 12 -
Operational Screens
User-Configurable Screens
The Centurion has (9) user-configurable pages of (4) types. The Centurion Configuration Tool software allows
users to configure up to nine (9) screens with controller input signal groupings. Possible custom screen types may
include:
a) Custom Line by Line allows users to display process data in a list format with description and value.
b) Custom Gage allows user to display four (4) most important pieces of data on a 2 x 2 table in larger font.
c) Custom Control Loop allows user to display Control Loop functions. The control output will be displayed
as a percentage of the range.
d) Custom Generic Register allows user to display up to 20 items on a page that can be mapped to the
Centurion Modbus map and given a label.
For more information on configuring the optional screens through the Centurion Configuration Tool, please refer
to the Configuration Tool Quick Start Guide.
Map of Operational Screens
From the Home Screen / Landing Page, use the left and right arrows to view the Operating Screens. A password
is not required to view these screens.
Some screens shown below are application specific and may not be used.
