Conguring G-SPEED Studio R
Viewing a List of Logical Drives
To view a list of logical drives, perform one of the following actions:
• Click the Logical Drive icon.
• From the Storage menu, choose Logical Drive.
The list of logical drives will appear. Logical drive information includes:
• ID – LD0, LD1, etc.
• Alias – If assigned
• Status - Normal, Critical or Oine icon
• Capacity – Data capacity of the logical drive
• RAID Level – Set when the logical drive was created
• Stripe – Set when the logical drive was created
• Cache Policy – Read and write cache settings
• Array ID – ID number of the disk array where this logical drive was created
Viewing Logical Drive Information
To view logical drive information:
1. Do one of the following actions:
• Click the Logical Drive icon.
• From the Storage menu, choose Logical Drive. The list of logical drives will
appear.
2. Mouse-over the logical drive you want, then click the View button.
Logical Drive information will display, including:
• Logical Drive ID – LD0, LD1, etc.
• Alias – If assigned
• Array ID – ID number of the disk array where this logical drive was created
• RAID Level – Set when the logical drive was created
• Operational Status – OK, Critical or Oine
