Galil DMC-1510 User Manual

156 • Appendices DMC-1500
Computer 9 pin to DMC-1500 Main Port Cable (9 pin)
9 PIN (FEMALE - COMPUTER) 9 PIN (FEMALE - CONTROLLER)
1 (Carrier Detect) 1
2 (Receive Data) 2
3 (Transmit Data) 3
4 (Data Terminal Ready) 4
5 (Signal Ground) 5
Controller Ground 9
Computer 25 pin to DMC-1500 Auxiliary Port Cable (9 pin)
25 PIN (MALE - TERMINAL) 9 PIN (MALE - CONTROLLER)
20 (Data Terminal Ready) 1
2 (Transmit Data) 2
3 (Receive Data) 3
8 (Carrier Detect) 4
7 (Signal Ground) 5
Controller +5V 9
Computer 9 pin to DMC-1500 Auxiliary Port Cable (9 pin)
9 PIN (FEMALE - TERMINAL) 9 PIN (MALE – CONTROLLER)
4 (Data Terminal Ready) 1
3 (Transmit Data) 2
2 (Receive Data) 3
1 (Carrier Detect) 4
5 (Signal Ground) 5
Controller +5V 9
