DMC-1500 Appendices • 167
AMP-11x0 Mating Power Amplifiers
The AMP-11X0 series are mating, brush-type servo amplifiers for the DMC-1500. The AMP-1110
contains one amplifier; the AMP-1120, two amplifiers; the AMP-1130, three; and the AMP-1140,
four. Each amplifier is rated for 7 amps continuous, 10 amps peak at up to 80 volts. The gain of the
AMP-11X0 is 1 amp/volt. The AMP-11X0 requires an external DC supply. The AMP-11X0 connects
directly to the DMC-1500 ribbon connectors, and screw-type terminals are provided for connection to
motors, encoders and external switches.
Features
• 6 amps continuous, 10 amps peak; 20 to 80 volts.
• Available with 1, 2, 3, or 4 amplifiers.
• Connects directly to DMC-1500 series controllers via ribbon cables.
• Screw-type terminals for easy connection to motors, encoders and switches.
• Steel mounting plate with 1/4" keyholes.
Specifications
Minimum motor inductance: 1 mH
PWM frequency 30 KHz
Ambient operating temperature
0-70° C
Dimensions 5.7" x 13.4" x 2.5"
Weight 4 pounds
Mounting
Keyholes - 1/4Φ
Gain 1 amp/volt
TERM-1500 Operator Terminal
Two types of terminals are offered from Galil; the handheld unit and the panel mount unit. Both have
the same programming characteristics.
Hand held unit is shown in the in the following:
