Configuration Description for DMC-1500
Jumpers
LABEL FUNCTION (IF JUMPERED)
SMX For each axis, the SM jumper selects the SM
SMY magnitude mode for servo motors or selects stepper
SMZ motors. If you are using a stepper motor for an axis,
SMW you must jumper SM for that axis. The analog motor
SME command is not valid with SM jumpered.
SMF
SMG
SMH
OPT Reserved
JP30,
JP31
Used to configure RS422 - main
JP31 Used to configure RS422 - auxiliary
MRST Master Reset enable. Returns controller to factory default settings and erases EEPROM. Depress
reset to activate.
Address Configuration Jumpers
ADD4 ADDR2 ADDR1 ADDRESS
OFF OFF OFF 0
OFF OFF ON 1
OFF ON OFF 2
OFF ON ON 3
ON OFF OFF 4
ON OFF ON 5
ON ON OFF 6
ON ON ON 7
Front Panel Baud Rate Switches
1200 9600 19.2 BAUD
ON ON OFF 300
ON OFF OFF 1200
ON OFF ON 4800
OFF ON OFF 9600
OFF OFF ON 19,200
OFF ON ON 38,400
ON ON ON Self Test
