DMC-1500 Chapter 9 Troubleshooting 131
Communication
Symptom Cause Remedy
Using COMDISK and
TALK2DMC, cannot communicate
with controller.
Baud Rate not correctly configured Check Baud rate switch positions
and registry settings for software
setup.
Hardware handshaking is not
enabled
(Must be enabled to use Galil
Software)
Set Hardware HSHK DIP switch
Serial Cable is not correct Use serial cable supplied by Galil
or Check pinouts for cable (see
appendix)
Incorrect Com Port Specified Change registry setting for com
port
Stability
Symptom Cause Remedy
Motor runs away when the loop is
closed.
Wrong feedback polarity. Invert the polarity of the loop by
inverting the motor leads (brush type)
or the encoder.
Motor oscillates. Too high gain or too little
damping.
Decrease KI and KP. Increase KD.
Operation
Symptom Cause Remedy
Controller rejects command.
Responded with a ?
Invalid Command Interrogate the cause with TC or
TC1.
Motor does not complete move. Noise on limit switches stops the
motor.
To verify cause, check the stop
code (SC). If caused by limit
switch noise, reduce noise.
During a periodic operation, motor
drifts slowly.
Encoder noise Interrogate the position
periodically. If controller states
that the position is the same at
different locations it implies
encoder noise. Reduce noise. Use
differential encoder inputs.
Same as above. Programming error. Avoid resetting position error at
end of move with SH command.
