5.5 Summary of LED Signals
The electronics of the GAT ECO.Lock 7xxx F/ISO are activated when the lock button is pressed in. The activation is
signaled by the status LED (LED ring flashes blue) that encircles the button. Additionally, the following lock states
are signaled by the status LED.
LED Ring
Meaning
Blue flash
Lock ready to read a data carrier
Red flash
- No authorization
- Error
Green flash
- Data carrier accepted
- Operation successful
Green flash and ascending
signal tone
Battery replacement successfully completed and lock again in the normal operating mode
Flashing red/green
Only in configuration mode: lock waiting to read a data carrier
5 x red flashes and
5 x signal tones
Battery change required
Figure 5.2 - Summary of the LED signals
