GPSMAP
®
2008/2108 Owner’s Manual 41
in s T a l l i n g Th e Un i T
NMEA Device
2
RXD+
RXD-
(LIGHT GREEN) NMEA 2 Out+
(PINK) NMEA 2 Out-
(VIOLET) NMEA 2 IN+
(GREY) NMEA 2 IN-
NMEA Device
2
RXD+
RXD-
NMEA Device
2
RXD+
RXD-
NMEA Device
2
RXD+
RXD-
(LIGHT GREEN) NMEA 2 Out+
(PINK) NMEA 2 Out -
(VIOLET) NMEA 2 IN+
(GREY) NMEA 2 IN-
GPSMAP 2008 Wiring Harness
PIN 8 - Black (Ground)
PIN 13 - Red (DC Positive)
PIN 7 - Yellow (Alarm)
PIN 12 - White (CANet H)
PIN 16 - Green (CANet L)
PIN 18 - Blue (NMEA Out)
GPSMAP 2008 Pin Assignment
NMEA Device
2
RXD+
RXD-
(LIGHT GREEN) NMEA 2 Out+
(PINK) NMEA 2 Out-
(VIOLET) NMEA 2 IN+
(GREY) NMEA 2 IN-
NMEA Device
2
RXD+
RXD-
NMEA Device
2
RXD+
RXD-
NMEA Device
2
RXD+
RXD-
(LIGHT GREEN) NMEA 2 Out+
(PINK) NMEA 2 Out -
(VIOLET) NMEA 2 IN+
(GREY) NMEA 2 IN-
GPSMAP 2108 Wiring Harness
PIN 8 - Black (Ground)
PIN 13 - Red (DC Positive)
PIN 7 - Yellow (Alarm)
PIN 18 - Blue (NMEA Out)
GPSMAP 2108 Pin Assignment
