• By—Enterthetargetlocationwithsettingsofdistance‘Before’or‘After’a
reference waypoint. To set a target location at a reference waypoint, enter a
distance of zero.
• VNAVMessages—Select‘On’or‘Off’toenable/disableVNAValertmessages.
2.4 USING MAP DISPLAYS
Map displays are used extensively in the GPSMAP 695/696 to provide situational
awareness in flight. Most GPSMAP 695/696 maps can display the following
information:
• Airports, NAVAIDs, airspaces, airways, land data (highways, cities, lakes, rivers,
borders, etc.) with names
•Map Pointer information (distance and bearing to pointer, location of pointer,
name, and other pertinent information)
•Maprange
•Aircrafticon(representingpresentposition)
•Flightplanlegs
•Userwaypoints
•Trackvector
•Topographydata
The information in this section applies to the following maps unless otherwise
noted:
•MapPage(MAP)
•WaypointPage(WPT)(INFO Softkey selected)
•WeatherPage(WX)
•Terrain(TER)
•NearestPages(NRST)
•ActiveFlightPlanPage(FPL)
•Direct-toWindow(maprangeonly)
