ASSEMBLY
8
Garrett Metal Detectors
1. Align the holes in the mounting washers with the
small posts on the lower stem and press firmly into
place.
2. Slide the searchcoil onto the stem.
3. Insert the threaded bolt through the holes of the
lower stem and searchcoil. Hand-tighten the
searchcoil assembly with the wing nut.
4. Depress the spring clip in the S-stem and insert the
control housing into the upper stem.
1. 2.
3. 4.
