GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
A-2
Table A-1
PTR-255 Remote Configuration Settings (P Codes)
1
Code
Digit(s) and
Switch
Equivalent
Description
SRVC
OFF
ON = Turns service on (module enabled)
OFF = Turns service off (module disabled)
P1
B00000000
---
TTS
Set the starting time slot. From left to right, these correspond to the
five TTS switches as described in Table 3-7, Starting Time Slot
Selection.
0 = Off, 1 = On
B00000000
-----
TOF
Must be set to 0.
P2
B00000000
---
RTS
Set the starting time slot. From left to right, these correspond to the
five RTS switches as described in Table 3-7, Starting Time Slot
Selection.
0 = Off, 1 = On
B00000000
-----
ROF
Must be set to 0.
P3
B00000000
----
TX GAIN LEFT
Set the left channel transmit gain control. Binary settings 0000
through 1111 are equivalent to the switch settings 0 through F
(hexadecimal) as described in Table 3-9, Gain Switch Settings.
B00000000
----
TX GAIN RIGHT
Set the right channel transmit gain control. Binary settings 0000
through 1111 are equivalent to the switch settings 0 through F
(hexadecimal) as described in Table 3-9, Gain Switch Settings.
P4
B00000000
------
TSR
Transmit sample rate. Same as Table 3-3, Sample Rate Settings.
0 = Up, 1 = Down
P4 (cont.)
B00000000
-----
TMOD
Transmit audio mode. Same as Table 3-2, Audio Mode Settings.
0 = Up, 1 = Down
B00000000
-----
TALGR
Transmit audio algorithm. Same as Table 3-1, Audio Algorithm
Settings.
0 = Up, 1 = Down
P5
B00000000
----
TDR
Transmit data rate. Same as Table 3-4, Data Rate Settings.
0 = Up, 1 = Down
1
The values shown are the only legal values for setting the parameters. Setting any
parameter to a value outside its specified range will produce an unpredictable result.
