GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
A-3
Table A-1
PTR-255 Remote Configuration Settings (P Codes)
1
Code
Digit(s) and
Switch
Equivalent
Description
B00000000
----
RDR
Receive data rate. Same as Table 3-4, Data Rate Settings.
0 = Up, 1 = Down
P6
B00000000
----
RX GAIN LEFT
Set the left channel receive gain control. Binary settings 0000 through
1111 are equivalent to the switch settings 0 through F (hexadecimal)
as described in Table 3-9, Gain Switch Settings.
B00000000
----
RX GAIN RIGHT
Set the right channel receive gain control. Binary settings 0000
through 1111 are equivalent to the switch settings 0 through F
(hexadecimal) as described in Table 3-9, Gain Switch Settings.
P7
B00000000
------
RSR
Receive sample rate. Same as Table 3-3, Sample Rate Settings.
0 = Up, 1 = Down
B00000000
-----
RMOD
Receive audio mode. Same as Table 3-2, Audio Mode Settings.
0 = Up, 1 = Down
B00000000
-----
RALGR
Receive audio algorithm. Same as Table 3-1, Audio Algorithm
Settings.
0 = Up, 1 = Down
P8
B00000000

Not used. Must be set to 0.
P9
B00000000
-----
BAUD
Auxiliary data channel baud rate.
000 = Off
001 = 1200 bps
010 = 2400 bps
011 = 9600 bps
B00000000
------
IMUX
Inverse multiplexing mode.
00 = None
01 = FHG
11 = CCS
B00000000
-------
DAB
DAB data compatibility.
0 = Standard MPEG bit stream
1 = DAB compliant bit stream
B00000000
-------
CAS
CAS signaling in an E1 multiplexer. In a non-E1 multiplexer, this bit is
ignored.
0 = CCS signaling (time slot 16 is available)
1 = CAS signaling (time slot 16 is reserved)
B00000000
-------
Not used.
